Description
This ultrasonic label sensor is an advanced solution for detecting a wide range of labels in automated labeling systems. Its robust ultrasonic technology ensures reliable performance regardless of material transparency, reflectivity, or color, making it highly versatile for industrial environments. The ultrasonic clear label sensor features easy push-button setup and dual NPN/PNP outputs for broad compatibility.
Specification
| Model | ATO-FGU03-C |
| Working Principle | Ultrasonic Technology |
| Housing Shape | Slot Type (Fork Shape) |
| Fork Width | 3 mm |
| Fork Depth | 69 mm |
| Minimum Detectable Object | Label gap/size: 2 mm |
| Setup Method | Plus/Minus Buttons (Teach-in, Sensitivity, Light/Dark Switch) |
| Supply Voltage | 10 – 30 V DC |
| Current Consumption | 40 mA |
| Switching Frequency | 1.5 kHz |
| Response Time | 250µs |
| Output Type | PNP and NPN |
| Max. Output Current | 100 mA |
| Connection Type | Connector, M8, 4-pin |
| Protection Class | IP65 |
| Housing Material | Metal, Aluminum |
Feature
-
Wide Detection Capability: The ultrasonic label sensor stably detects transparent labels, non-transparent labels, paper labels, PVC composite labels, and metallic labels such as gold or silver stamped varieties.
