Belimo F665VIC+AFX24-MFT-X1 2-Way 2-1/2″ Butterfly Valve, ANSI Class Grooved AWWA, Cv 260 + Spring Return Valve Actuator, 24VAC/DC, Programmable (2-10VDC Default) Control Signal

Description

Belimo F665VIC+AFX24-MFT-X1 : 2-Way 2-1/2″ Butterfly Valve, ANSI Class Grooved AWWA, Cv 260 + Spring Return Valve Actuator, 24VAC/DC, Programmable (2-10VDC Default) Control Signal

Belimo F665VIC butterfly valve assembly with AFX24-MFT-X1 actuator provides dependable flow control for chilled water and hot water HVAC hydronic systems. The actuator supports modulating control and common building automation sequences. Use the specifications below to confirm pressure class, voltage, control signal, and enclosure rating before ordering.

Belimo F665VIC Valve Specifications

ANSI Class	Grooved AWWA
Pattern	2-way
Cv	260
Fluid	Chilled or hot water, up to 60% glycol
Body Pressure Rating	ANSI Class Grooved AWWA, 300 psi
Flow characteristic {Tools}	Modified equal percentage
End Fitting	Grooved
Valve Size	2.5″ [65]



Belimo AFX24-MFT-X1 Valve Actuator Specifications
