Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 32 Cv
- Pipe/Port Type and Size: NPT 1 1/4
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Product Weight: 10.54 lbs
- Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
- Watt Rating: 15.4 W
- Holding Current (VA): 27
- Orifice Size: 1-5/8 in
- Coil Class: FT
- Coil Number: 400525-125
- Mounting Direction: Vertical and Upright
- Carton Note: 1-1/4 X 1-5/8 2NC AL 15.4/F AC
- Kit Number: 302352
