Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 32 Cv
- Pipe/Port Type and Size: NPT 1 1/4
- Min Operating Pressure (Air): 0 psi
- Max Operating Pressure (Air): 25 psi
- Product Weight: 9.06 lbs
- Voltage and Frequency: 110 Volts AC with 50 Hz
- Watt Rating: 15.4 W
- Orifice Size: 1-5/8 in
- Coil Number: 099257-001-D
- Lead Length: 18 inch
- Carton Note: 1-1/4 X 1-5/8 2NC AL 15.4/F AC
- Kit Number: 302352
