Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 1.5 Cv
- Pipe/Port Type and Size: NPT 1/4
- Media: Air, Inert Gas
- Min Operating Pressure (Air): 15 psi
- Max Operating Pressure (Air): 150 psi
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 140°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 0 lbs
- Voltage and Frequency: 220 AC, 240 AC with 50/60 Hz
- Watt Rating: 10.1 W
- Orifice Size: 5/16 in
- Coil Class: HT
- Coil Number: 238814-058-D
- Lead Length: ANY, 18 inch
- Carton Note: 1/4 X 5/16 3NC BRASS 10.1/H AC
- Kit Number: 318180-V
