Description
Specifications
- Valve Actuation: Solenoid
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 50 Cv
- Pipe/Port Type and Size: NPT 1-1/2
- Min Ambient Temperature: 0°
- Max Ambient Temperature: 150°
- Min Fluid Temperature: 0°
- Max Fluid Temperature: 150°
- Voltage and Frequency: 480 Volts AC with 60 Hz
- Watt Rating: 10.1 W
- Holding Current (VA): 25
- Orifice Size: 2 in
- Coil Class: FT
- Coil Number: 238614-088-D
- Lead Length: Any, 18 inch
- Carton Note: 1-1/2 X 2 2NC AL 10.1/F AC
- Kit Number: 322108
