Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 3.2 Cv
- Pipe/Port Type and Size: NPT 1/2
- Media: Air, Inert Gas, Water
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 250 psi
- Min Operating Pressure (Water): 10 psi
- Max Operating Pressure (Water): 250 psi
- Product Weight: 4.1 lbs
- Voltage and Frequency: 220 AC, 240 AC with 50/60 Hz
- Watt Rating: 17.1 W
- Orifice Size: 5/8 in
- Coil Class: F
- Coil Number: 238614-158-D
- Lead Length: 18 inch, ANY
- Carton Note: 1/2 X 5/8 3NC BRASS 17.1/F AC
- Kit Number: 314495-MO
