Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 2.5 Cv
- Pipe/Port Type and Size: NPT 3/8
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 4.1 lbs
- Voltage and Frequency: 24 AC with 60 Hz
- Watt Rating: 17.1 W
- Orifice Size: 5/8 in
- Coil Class: FB
- Coil Number: 238614-105-D
- Lead Length: 18 inch, ANY
- Carton Note: 3/8 X 5/8 3NC BRASS 17.1/F AC
- Kit Number: 314495-MO
