Specifications
- Valve Actuation: Solenoid
- Function: 2 way – 2/2 Normally Open
- Body Material: Brass
- Flow (Cv): 22.5 Cv
- Pipe/Port Type and Size: NPT 1-1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 210°
- Product Weight: 6.79 lbs
- Voltage and Frequency: 110 AC with 50 Hz
- Watt Rating: 16.1 W
- Orifice Size: 1-1/4 in
- Coil Class: HT
- Coil Number: 272814-029-D
- Mounting Direction: 18 inch, Any
- Carton Note: 1-1/2 X 1-1/4 2NO BRASS 16.1/H AC
- Kit Number: 310494
