Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 4.4 Cv
- Pipe/Port Type and Size: NPT 1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Product Weight: 1.7 lbs
- Voltage and Frequency: 24 Volts DC
- Watt Rating: 11.6 W
- Orifice Size: 3/4 in
- Coil Class: FT
- Coil Number: 238714-006-D
- Mounting Direction: Vertical and Upright, 18 inch
- Carton Note: 1/2 X 3/4 2NC AL 11.6/F DC
- Kit Number: 302430
