Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 35 Cv
- Pipe/Port Type and Size: NPT 1 1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
- Watt Rating: 15.4 W
- Holding Current (VA): 27
- Orifice Size: 1-5/8 in
- Coil Class: FT
- Coil Number: 099257-001-D
- Lead Length: 18 inch, Vertical and Upright
- Carton Note: 1-1/2 X 1-5/8 2NC AL 15.4/F AC
- Kit Number: 302358
- Order Code: 20311
