Description
Specifications
- Valve Actuation: Solenoid
- Function: 4 way
- Body Material: Brass
- Flow (Cv): 0.09 Cv
- Pipe/Port Type and Size: NPT 1/4
- Media: Air, Inert Gas
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 100 psi
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Product Weight: 2.01 lbs
- Voltage and Frequency: 24 Volts DC
- Watt Rating: 11.6 W
- Orifice Size: 1/16 in
- Coil Class: F
- Coil Number: 238710-006-D
- Mounting Direction: 18 inch, Any
- Carton Note: 1/4 X 1/16 4W BRASS 11.6/F DC
- Kit Number: 302702-MO
