Description
Specifications
- Product Type: Solenoid Valve
- Valve Actuation: Solenoid – Direct Acting
- Function: 4 way
- Body Material: Brass
- Flow (Cv): 0.8 Cv
- Pipe/Port Type and Size: NPT 1/4
- Media: Air, Inert Gas, Light Oil, Water
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 250 psi
- Min Operating Pressure (Water): 10 psi
- Max Operating Pressure (Water): 250 psi
- Min Operating Pressure (Light Oil): 25 psi
- Max Operating Pressure (Light Oil): 250 psi
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 4.48 lbs
- Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
- Watt Rating: 17.1 W
- Holding Current (VA): 40
- Orifice Size: 1/4 in
- Coil Class: FB
- Coil Number: 238610-132-D
- Mounting Direction: Any, 18 inch
/ul>
