AccuEnergy ACUVIM-3-M-5A-P2 Acuvim-3 Advanced Power Quality Meter, Din Rail Mount Without Lcd, 5A/1A Current Input (Field Selectable), 20-60Vdc Auxiliary Power Supply

Description

AccuEnergy ACUVIM-3-M-5A-P2 : Acuvim-3 Advanced Power Quality Meter, DIN Rail Mount Without LCD, 5A/1A Current Input (Field Selectable), 20-60Vdc Low Voltage DC Control Power (P2)

The AccuEnergy Acuvim-3 Advanced Power Quality Meter is an advanced power quality meter and revenue grade energy meter designed for critical power monitoring and reporting. It is compliant to IEC 61000-4-30 Class A and supports high-accuracy metering with waveform capture, harmonics analysis up to the 127th, onboard data logging, and flexible communications for SCADA, BAS, and industrial power systems. For local viewing, the Acuvim-3 can be paired with the optional remote display module or accessed via a web interface.

Common Applications

• Data centers, UPS systems, and critical infrastructure power monitoring
• Power distribution, substations, and energy management projects
• Industrial automation and manufacturing facility power quality tracking
• DER, microgrids, and virtual power plant performance monitoring

Specifications

• Model Configuration
  • Mounting: M (DIN rail mount without LCD)
  • Current Input: 5A (5A/1A input, field selectable)
  • Aux Power: P2 (20-60Vdc low voltage DC control power)
• Power Quality and Revenue Grade Metering
  • Power quality monitoring compliant to IEC 61000-4-30 Class A
  • Revenue grade accuracy: IEC 62053-22 Class 0.1S and ANSI C12.20 Class 0.1
  • Harmonics measurement up to the 127th
• Logging and Waveform Capture
  • Sampling rate up to 1024 samples/cycle
  • Waveform capture detection up to 512 samples/cycle, stored in COMTRADE format
  • 32 GB onboard data logging with configurable dataloggers
• Communications and Integration
  • Multi-protocol support includes IEC 61850, Modbus RTU, Modbus TCP/IP, BACnet IP, BACnet MS/TP, DNP3 TCP, and SNMP
  • Interfaces include dual Ethernet, RS485, Wi-Fi, IRIG-B, digital I/O, and USB-C
