Description
1 kVA variac transformer single phase, frequency 50Hz or 60Hz, 110V/220V input voltage is optional.
Note: Support the split phase (L1,L2+N,G), Please contact us.
1 kVA Single Phase Variac Voltage Regulator Features
1 kVA variac variable transformer, single phase, working frequency is 50Hz, rated input voltage is 220V. It is a light weight, low cost and long life line reactor for generator.
1 kVA Single Phase Variac Voltage Regulator Specifications
| Model | ATO-TDGC2-1K | |
| Phase No | 1 | |
| Frequency | 50/60Hz | 60Hz |
| Rated Input Voltage | 220V | 110V |
| Rated Output Voltage | 0~250V | 0~130V |
| Rated Capacity | 1 kVA | 1 kVA |
| Max Output Current | 3.2AA | 6.1A |
| Usage | SVC | |
| Current Type | AC | |
| Actual Output Current | (actual output voltage * rated current) / maximum output voltage | |
| Type | Contact Type Regulators | |
| Weight | 6kg | |
| Dimension | 440*245*450mm |
1 kVA Sing Phase Variac Voltage Regulator Detail
Tips: Characteristics of Variac Voltage Regulator
- Adopt vacuum adjustment switch, voltage adjustment sensitivity and output stability.
- When the grid voltage fluctuates, in order to provide a high-quality stable voltage, the voltage of the transformer must be adjusted.
- The integrated voltage regulator transformer has compact structure, small footprint and convenient installation.
- Tap-changer power distribution automatic controller, convenient for on-site remote control, can be provided for computer interface.
