Description
Best 1 hp (0.75 kW) variable frequency drive, single phase 220v to three phase 380v VFD for AC motor speed control, 400v/ 415v output for choice.
Specification:
| Basics | Model | GK3000-CS0007 |
| Capacity | 1 hp (0.75 kW) | |
| Shipping weight | 3 kg | |
| Dimension | 236*130*176 mm | |
| Installation size | 222*116 mm | |
| I/O Feature | Rated current | 2.1 A |
| Input voltage | 1 phase 220~240V AC | |
| Input frequency | 50Hz/ 60Hz | |
| Output voltage (Optional) | 3 phase AC 380V/ 400V/ 415V/ 440V/ 460V (Note: 440V, 460V output voltage only for the 1-phase 240V input VFD) | |
| Output frequency | 0Hz~1000Hz | |
| Over load capacity | 150% of rated current for 1 minute, 180% of rated current for 3 seconds | |
| Control Feature | Control mode | V/F control; Sensorless vector control; |
| Communication | RS485 | |
| Speed regulation | 1:100 | |
| Start torque | 150% of rating torque at 1 Hz | |
| Speed control accuracy | ≤±0.5% of rating synchronous speed | |
| Frequency precision | Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2% |
|
| Frequency resolution | Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz |
|
| Torque boost | Automatic torque boost, manual torque boost 0.1%~30.0% | |
| Interior PID controller | Be convenient to make closed-loop system | |
| Automatic energy save running | Optimize V/F curve automatically based on the load to realize power save running | |
| Automatic voltage regulation (AVR) | Can keep constant output voltage when power source voltage varies. | |
| Automatic current limiting | Limit running current automatically to avoid frequent over-current which will cause trip | |
| Environment | Enclosure rating | IP 20 |
| Temperature | –10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5% | |
| Humidity | 5%-95%, without condensation | |
| Altitude | ≤1000m; VFD will be derated if above 1000m | |
| Impingement and oscillation | Normal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g) | |
| Store environment | –20℃~ +60℃; no dust, no corrosive gas, no direct sunlight |
Note: ATO VFD Cannot be used as a power source, it Can only be directly connected to an induction motor to control the motor speed.
Details
Tips: Why you need a 1-phase 220V to 3-phase 380V VFD?
Due to national policies and regional restrictions, many areas will now withdraw 3-phase 380V industrial power. No 3-phase power in the region to apply for 3-phase power cumbersome procedures and a variety of labor costs and various hidden costs, resulting in some areas can not use industrial 380V power. and general industrial equipment, such as AC motors are mostly 3-phase 380V, in the absence of 3-phase electricity can not run. We can only find ways to convert 1-phase 220V to 3-phase 380V. However, many single phase 220V to three phase 380V equipment on the market are ridiculously expensive, so many users in need are discouraged. And the original machine can only be temporarily placed, or put into other places with industrial electricity to use.
ATO offers a series of 1-phase 220V input to 3-phase 380V output variable frequency drive from 1hp to 20 hp, which can drive 3-phase asynchronous motor soft start operation, for infinitely adjustable speed. The input power only needs single phase 220V, output three phase 380V, and the price is acceptable to most users. Our VFDs are about 1/10 of the price of the booster on the market, compact size, powerful, 0-400Hz can be adjusted at will, completely solve the embarrassing situation of industrial equipment without 3-phase power.
