Description
Eliminators of this type consists of oil mist inlet and outlet, three types of filters including primary, secondary and HEPA filters, a centrifugal impeller, a brushless motor and an oil collecting tank. This model belongs to centrifugal category in terms of its working principle. With the rated power of 750W (1hp), it is energy efficient and environmentally friendly.
Features:
- This series of oil mist eliminators adopt a full-metal framework which will protect the main body from strong impact.
- Powered by brushless motor with advantages of quiet operation, high rotary speed, accredited stability, long life cycle, high efficiency and low energy consumption.
- Equipped with a vortex alloy wind turbine and designed for continuous use with large air volume and a powerful suction.
Specifications
| Model | ATO-OME-DER-YQ750 |
| Voltage | 380V (three-phase) |
| Power | 750W |
| Wind Pressure | 1200Pa |
| Air Volume | 800 m³/h |
| Noise | 60dB |
| Efficiency | 99% |
| Diameter of inlet | 148mm |
| Diameter of outlet | 14mm |
| External dimension | 650*370*470mm |
| Installation dimensions | 290*320mm |
| Weight | 45Kg |
Product structure diagram
Tips: Advantages of oil mist eliminators
- High efficiency and energy-saving with purification rate over 99%.
- Endurable for heavy use with no consumables. Helpful for the improvement of workplace and realizing clean production.
- Useful for the protection of workers’ physical and mental health by reducing the risk of developing occupational diseases.
- Minimizing the influence of fume or oil mist on the circuit and control systems which subsequently brings down the maintenance cost of machine tools.
- The oil mist cleaner can recycle the cooling oil condensed from the oil mist emitted from the cold heading machine, thus reducing production costs.
