Description
Magnetic water pump adopts solid TEFC construction motor, painted with 2 parts epoxy paint. 0.4 hp (0.33 kW) magnetic pump without seal, can achieve zero leakage, especially suitable for conveying flammable, explosive, corrosive liquid.
Features:
- The motor is of solid TEFC construction and is painted with 2 parts epoxy paint.
- Offering ceramic bearing and ceramic spindle as standard wearing parts to achieve long life expectancy.
- Standard connections available in hose, threads or union type.
Specification:
| Model | ATO-300PS-F | ||
| Frequency | 50Hz, 60Hz | ||
| Rated Voltage | 3-phase 380V (contact us for other voltages) | ||
| Connection Method | Hose (mm) | Thread (“) | Flange (A) |
| 26×20 | 1×3/4 | 25×25 | |
| Pump Performance at Specific Point | 50Hz | 50 L/min | |
| 60Hz | 50 L/min | ||
| Rated Head | 50Hz | 16m | |
| 60Hz | 21m | ||
| Motor Output | 330W | ||
| Net Weight | 13kg |
Dimension (Unit: mm)
| Model | W | H | L | a | b | c | d | e | f | g |
| 300PS-F | 160 | 175 | 385 | 50 | 110 | 181 | 110 | 75 | 55 | 47.5 |
Application:
Tips: Magnetic Drive Pump Using Tips
- Proper installation. Magnetic drive pumps should be installed in a stable, level location with enough space around the pump for maintenance and repairs.
- Appropriate materials. Choose a magnetic drive pump that is made of materials that are compatible with the fluid being pumped.
- Correct flow rate. Make sure that the pump is sized properly for the desired flow rate.
- Regular maintenance. Regular maintenance is essential for magnetic drive pumps to keep them functioning properly. This includes checking for leaks, replacing worn seals, and cleaning the pump internals.
- Avoid dry running. Never run a magnetic drive pump dry as this can cause damage to the pump internals.
