Description
223 1kV disc ceramic capacitor is a high voltage power capacitor with 10mm lead pitch, which can be used for negative ion products, lasers, X-ray machines, control and measurement equipment, high-voltage packages, igniters, generators, transformers, power equipment, voltage doubling modules, welding machines, electrostatic spraying and other electromechanical equipment that requires high voltage and high frequency.
Specification
- Model: ATO-1KV223K
- Series: High Voltage Disc Ceramic Capacitor
- Capacitance: 0.022μF (22000pF, 22nF)
- Rated voltage: 1kV (1000V)
- Tolerance: 10%
- Dielectric Material: Y5T
- Operating Temperature Range: -40℃ – 105℃
- Feature: High Frequency
- Lead Type: Radial Lead Wire
- Lead Pitch: 10mm
- Size: 6.5mm
- Installation Type: In-line
- Package: DIP
- Application: Household Appliances
- Medium Material: Ceramic (Porcelain)
- Loss: 0.01%
- Weight: 0.02kg
Note:
- Capacitance: Under 1KHz (CLASSII), or 1MHz (CLASSI) and 25℃±2℃, Vrms = 1.0V conditons, not exceed capacitance tolerance.
- Dissipation factor(D.F.): SL. YL Q> 1000, Y 5P Y 5U Y5V D.F. < 2.5%, Bn D.F. <0.5%, 2R D.F. <0.1%
- Insulation resistance: At DC500V voltage for 1 minute CASSAII.R. ≥10,000MΩ, CLASSIII.R. ≥4000MΩ
- Test voltage: UR< 6kV, Ut=1.5UR + 500V UR≥ 6kV, Ut = 1.5 x UR
Tips: High voltage ceramic capacitor advantages
- The capacitance loss of high voltage ceramic capacitors has high stability with temperature and frequency.
- The special series structure of high voltage ceramic capacitors is suitable for high-voltage extremely long-term working reliability.
- High voltage ceramic capacitors have high current ramp rates and are suitable for non-inductive structures in large current loops.
